Dimensions in mm, Figure 25, Dmt143 dimensions – model with iso thread – Vaisala DMT143 User Manual
Page 75: Figure 26, Dmt143 dimensions – model with npt thread
Chapter 8 _____________________________________________________________ Technical Data
VAISALA ________________________________________________________________________ 73
Dimensions in mm
1202-130
Figure 25
DMT143 Dimensions – Model With ISO Thread
1202-131
Figure 26
DMT143 Dimensions – Model With NPT Thread
91.6
57
22.5
12
28
AW24
G1/2" ISO228/1
91.6
22.5
49.1
AW30
NPT1/2"
12
32
