Remote probe model – Vaisala HMT100 User Manual
Page 27

Chapter 4 ______________________________________________________________ Maintenance
VAISALA _______________________________________________________________________ 27
Remote Probe Model
1.
Unscrew the small sleeve that secures the probe in place at the end
of the probe cable and pull out the probe.
2.
Replace the probe and screw the small sleeve back on, securing the
probe tightly in place.
1
3
2
0506-006
Figure 12
Removing the Humidity Probe (Remote Probe
Model)
The following numbers refer to Figure 12 above:
1 =
Probe
cable
2
=
Sleeve securing the probe to the cable
3 =
HMP100
probe
