Chapter 5 _________________________________________________ Buttons, Displays and Menus
VAISALA _______________________________________________________________________ 19
Graphical Display
Graphical display shows you the measurements in a form of curve.
From the curve you can examine the data trend and history of the last
minutes. Graphical display shows firstly the curve of the uppermost
quantity shown in a basic display.
1. In basic display, press Graphic or (alternatively open the MENU,
select Display, select Graphic history
2. Graphical display opens. More information on page 23 Graphic
history .
3. Press BACK to return to the basic display.
Menus
In the menus you can change settings and select the functions.
1. Open the main menu by pressing any of the buttons.
2. Press OPEN within 5 seconds. The basic display returns if you
do not open the MENU shortly. If this happens, begin with the item
1 again.
3. Move in the menus by using buttons.
4. Select the item with buttom.
5. Press to return to the earlier level.
6. EXIT returns back to normal operation.
Main menu Display menu
Functions menu Recording/Viewing menu
Settings menu Environment menu
