Vaisala HM44 - Manual (Page 31)

Chapter 7 _____________________________________________________ Transferring data to a pc
VAISALA __________________________________________________________________________ 29
Giving the communication parameters
Give the communication parameters when using this terminal session for the first time; save
them for future use. See instructions in the following tables.
Table 7.1 Giving parameters in Windows 3.1
MENU DESCRIPTION
P ROGRAM M ANAGER
ò
A CCESSORIES double click
ò
T ERMINAL double click
ò
Settings click
ò
Communications
click and select parameters
(see figure 7.2); click OK
ò
move the cursor to:
File click
ò
Save as click and save settings: type
the name of the file (e.g.
HMI41) and click OK
Turn the HMI41 on, and follow the instructions on page
32.
Figure 7.2 Giving the communication parameters in Windows 3.1
NOTE: select the
connector accord-
ing to your
computer. Select
the connector first
and give then
other parameters
