WeatherHawk ® 27
815 W. 1800 N. Logan, Utah 84321-1784, Email: [email protected] Copyright © 2004, 2010
Toll free in USA: 866-670-5982, International: 435-750-1802, FAX: 435-750-1749 Printed November 2010
A.2. Power Supply Options
A.2.1. SP2-KT Solar Panel Kit (pn. 16851)
The SP2-KT is a solar panel kit for recharging the internal battery. It has a 72 inch
2
surface area and produces 5 W of
power at a peak of 17.1 V. The SP2-KT includes:
•
5 W solar panel
•
Mounting hardware
A.2.2. ACP1 AC Converter (pn. 18863)
The ACP1 recharges the WeatherHawk battery by converting 110-220 VAC, 50/60 Hz power to 18 VDC. It must be
housed in a non-condensing environment or a weatherproof enclosure. The ACP1 includes:
•
UL-approved, AC/DC converter with US Standard plug prongs 20 feet (6.2 m)
•
UV resistant waterproof cable with an environmental connector for connecting to the WeatherHawk station.
A.3. Instrument Mounts and Mounting Hardware
A.3.1. Grounding Kit (pn. 21660)
The Grounding Kit provides the equipment required to properly ground the system. It is included with the CM375
mast, but can also be purchased separately for preinstalled towers or masts. This kit consists of:
•
Lightning rod
•
Lightning rod bracket
•
U-bolt with matching nuts
•
Copper grounding rod
•
Ground wire
•
Ground wire clamp
•
Locking nut
