Welcome to the OutBack Power Systems FX Series Inverter/Charger System

The FX Series Inverter/Charger off ers a complete power conversion system—DC to AC, battery
charging, and an AC transfer relay—and can be used as a stand-alone or back-up application. It is
designed for indoor or enclosed locations.

OutBack Power Systems does everything possible to assure the components you purchase will
function properly and safely when installed as instructed according to local and national electrical
codes. Please read all of the following instructions and the instructions that come with any OutBack
components that make up your power system. Further instructions on individual FX set-ups as well as
system assemblies are included with the FLEXware manuals.

• The Export FX is CE tested (see “EU Declaration of Conformity” on the previous page).

The International FX and VFX Series Inverter/Charger Installation Manual covers the following information:
• Safety
• FX parts, standard and optional
• Initial inspection of the component
• Preparing the mounting surface
• Fastening the FX to the mounting surface
• General electrical information

E Series FX Series Inverter/Charger Models

Sealed Units (designed for harsher environments, but still require enclosed protection)

FX2012ET (12 VDC/2000 VA) 230VAC/50 Hz
FX2024ET (24 VDC/2000 VA) 230VAC/50 Hz
FX2348ET (48 VDC/2300 VA) 230VAC/50 Hz

Vented Units (designed for more protected environments)

VFX2612E (12 VDC/2600 VA) 230VAC/50 Hz
VFX3024E (24 VDC/3000VA) 230VAC/50 Hz
VFX3048E (48 VDC/3000VA) 230VAC/50 Hz

Each model FX has a single phase output marked with this symbol:
Each inverter puts out a sine wave waveform marked with this symbol:

Parts Included

• One E Series FX Series Inverter/Charger
• One “WARNING ELECTRICAL SHOCK” sticker to place on the exterior of the FX
• One packet of silicone grease to protect CAT 5 cable connections
• One installation manual
• One programming manual
• One Turbo Kit (sealed units)
• One DC Wiring Cover or DCC (vented units)
• DC terminal covers (one red and one black)
• AC Wire Compartment Plate
