Page 38

36
FX2012ET
AC Max = 6AAC (Default = 5 AAC)
DC Max = 100ADC
FX2024ET
AC Max = 7AAC (Default = 5 AAC)
DC Max = 55ADC
FX2348ET
AC Max = 7AAC (Default = 5 AAC)
DC Max = 35ADC
VFX2612E
AC Max = 7AAC (Default = 6 AAC)
DC Max = 120ADC
VFX3024E
AC Max = 10AAC (Default = 9 AAC)
DC Max = 85ADC
VFX3048E
AC Max = 10AAC (Default = 9 AAC)
DC Max = 45ADC
AC INPUT FREQUENCY RANGE
NOTE: If the AC input source is out of the range noted below, the FX will not connect or stay connected.
All E Series FX Models
44-56 Hz
MAXIMUM AC OUTPUT CURRENT
This is the amount of surge current that the FX will quickly supply for a split second. Depending on the
size of the surge, the FX can be overloaded for a minimum time of 5 seconds to a maximum time of 30
minutes.
All 12 VDC FXs
28AAC per FX for 1 millisecond
All Other FXs
35AAC per FX for 1 millisecond/25AAC per FX for 100 milliseconds
MAXIMUM CONTINUOUS OUTPUT POWER
An FX Series Inverter/Charger’s model number indicates its maximum continuous output power by
changing the last two digits to zeros. For instance, an FX2012ET has a maximum continuous output
power of 2000VA (volt-amps).
FX2012ET
2000VA (VA = volt-Amps)
FX2024ET 2000VA
FX2348ET 2300VA
FX2612E 2600VA
VFX3024E 3000
VA
VFX3048E 3000VA
MAXIMUM AND DEFAULT AC INPUT AND DC CHARGER (bulk stage) OUTPUT VALUES
