30

INSTALLATION CHECK LIST

ITEM

YES NO

All manuals read and reviewed?

FX

OutBack

Charge

Controller

MATE

HUB

System mounted with the recommended number and sized fasteners?

System installed according to local codes?

System inspected?

System permanently grounded?

Did the installer use OutBack recommended wire type and gauge adjusted for
temperature ratings and length?

All AC wiring rated for 75° C or higher?

Battery cables rated 75° C or higher?

6.0 mm

2

(10 AWG) wire used for AC Input Hot?

6.0 mm

2

(10 AWG)or larger wire used for AC HOT OUT?

FX connected to AC circuit with 30 amp maximum branch-circuit
over-current protection?

All cables torqued to OutBack specifi cations?

AC and PV breakers to 22 inch-lbs/2.48 Nm?

All DC connections to 10 foot-lbs/13.6 Nm?

FX AC terminals to 30 inch-lbs/3.38 Nm?

FX battery breaker to 45 inch-lbs/5.07 Nm?

All terminal block screws torqued to 2.5 foot-lbs/3.4 Nm?
