WIRE SIZES

The following chart contains information on wire sizes, the DC resistance of the wires and the

corresponding diameters and areas of these wires. This information can be used to calculate the

voltage drop of the wires or to fi nd an equivalent wire size.

SIZE

DC

CROSS-SECTIONAL AREA

APPROXIMATE DIAMETER

(AWG)

Resistance in Ohms

(1000

feet)

INCHES

MILLIMETERS

INCHES

MILLIMETERS

14 3.14

.0032

2.08

.0641 1.63

12 1.98

.0051

3.31

.0808 2.05

10 1.24

.0082

5.26

.1019 2.59

8 0.78 .0130

8.37

.1285 3.26

6

0.50

.0206 13.30 .162

4.11

4

0.31

.0328 21.15 .2043

5.19

2

0.19

.0521 33.62 .2576

6.54

1

0.15

.0657 42.41 .2893

7.35

1/0

0.12

.0829 53.50 .325

8.25

2/0

0.10

.1045 67.43 .365

9.27

3/0

0.08

.1318 85.01 .410

10.4

4/0 0.06

.1662

107.20

.460

11.7

MODEL

AMPACITY

DC BREAKER

DC FUSE

FX2012ET 200

amps

OBB-250-125VDC-PNL 400

FX2024ET 125

amps

OBB-175-125VDC-PNL 200

FX2348ET 57.5

amps

OBB-125-125VDC-PNL 200

VFX2612E 260

amps

OBB-250-125VDC-PNL 400

VFX3024E 150

amps

OBB-250-125VDC-PNL 200

VFX3048E 75

amps

OBB-125-125VDC-PNL 200

MAXIMUM OVERCURRENT PROTECTION AMPACITY

This rating specifi es the proper overcurrent protection ampacity.

• OBDC breakers are panel-mount circuit breakers.

• Class T DC fuses are terminal-mounted and should always be used in conjuncture with a disconnect mechanism.

• FXs used in home installations should use properly sized DC circuit breakers.

• A DC breaker includes both overcurrent protection and disconnect capability.

• OutBack Power Systems recommends Class T fuses for marine installations where a DC disconnect is not required.
