35

NOTE:

This is the maximum continuous DC current that the FX can send to the batteries when charging.

FX2012ET

100ADC (ADC = Amps DC)

FX2024ET 55ADC

FX2348ET 35ADC

VFX2612E 120ADC

VFX3024E 85ADC

VFX3048E 42ADC

AC INPUT OPERATING VOLTAGE RANGE

NOTE:

This is the recommended AC input voltage range to be supplied to the FX. Voltages outside of

this range may damage AC loads connected to the FXs AC output terminals.

All E Series FX Series Inverter/Chargers 160-300VAC (VAC = volts AC)

MAXIMUM AC INPUT CURRENT

An AC input source connected to the FX supplies power for two separate internal AC circuits – the AC

transfer relay and the battery charging system. The AC transfer relay transfers the AC input power to

the AC loads. The FX’s battery charger will “back off ” if the total AC loads—including the charger—

exceed the AC input current limit (default setting is 28 AAC). This “Input Limit” can be adjusted using

the MATE to avoid overloading a generator or trip a circuit breaker. If your generator cannot produce

28 AAC or you are connecting to an AC input source that has a breaker that is rated for less than 30

AAC, please refer to the FX and VFX Series Inverter/Charger Programming Manual to change this

setting.

All E Series 230 VAC FXs

30AAC per FX (AAC = Amps AC)

MAXIMUM CURRENT FOR BATTERY CHARGER

Due to heat restraints, the FX limits incoming AC current to recharge the battery. Please refer to the FX

and VFX Series Inverter/Charger Programming Manual to adjust this setting. The battery charger has

an effi

ciency of 90%. Other factors, such as cable losses, might reduce this effi

ciency.

RATED DC CHARGING CURRENT
