ADSL2/2+ Router
- 97 -
no matter which standard it complies with: 802.11b, 802.11g or
802.11n. (Different wireless network standards have different
maximum transmission rates:802.11b mode is at 11Mbps,
802.11g mode at 54 Mbps and 802.11n mode at 150Mbps. And
devices that adopts 2T2R can reach up to 300Mbps ).
b/g Mixed Mode: If this mode is selected, then wireless adapters
in use must support 802.11b or 802.11g mode.
g Mode:If this mode is selected, then wireless adapters in use
must support 802.11g mode.
SSID: the name of wireless network. It can divide a wireless LAN
into several sub-networks that requires different identity
authentication, and allows itself to be scanned by other wireless
devices through broadcast. The name displayed in “View
available wireless networks” under Windows is a SSID.
Hide SSID: If you do not want wireless network to be searched
by other users via SSID name, then you had better prohibit SSID
broadcast. As a result, your wireless network will not appear in
the searched wireless network list but it is still available, you only
need to add it to the list manually. The following example teaches
you how to add a wireless network under Windows 7:
