ADSL2/2+ Router
- 60 -

PPP Password: The password provided by your ISP for PPPoE
dialup.

PPPoE Service Name: It is provided by your ISP. Do not fill it in if
you don’t have it; otherwise PPPoE dialup may fail

Authentication Method: It is used by ISP to verify its clients
during PPPoE dialup. Select “Auto” if you are not sure about it.

Clone MAC：This feature clones the MAC address of the PC
that is currently entering the router’s management page to work
as the WAN MAC address of the router. Configure it when your
ISP requires a fixed MAC for your Internet access.

Dial on Demand: Automatically connects or disconnects Internet
according to the use of the network. It is recommended when
your ISP limits network use time. This feature can help you to
save the Internet fee.

PPP IP extension: The IP addresses of all packets including
management packets that egress WAN port will be converted to
the WAN port’s IP address once this feature is enabled.

Enable PPP Debug Mode: This feature can be enabled only
when supported by your ISP.

Bridge PPPoE Frames Between WAN and Local
Ports：PPPoE dialup frame initiated by LAN port will directly
egress WAN port without being modified if this feature is enabled.

Multicast Proxy: Router enables multicast proxy server if this
feature is enabled.
Enter the PPP user name and PPP Password provided by your ISP.
For other options, keep the default values if you are not clear about
