Introduction
Page 1-2
IntraSwitch 5324
The Asanté IntraSwitch 5324 is a high-performance, manageable
Ethernet switch that offers 24 10Base-T ports, one 10/100TX
port, and two optional Media Independent Interface (MII)
expansion slots.
The MII expansion slots allow for the addition of 10/100TX,
100Base-FX, or 10Base-FL connections. See page 2-13 for more
details.
Figure 1-1
IntraSwitch 5324 front panel
Figure 1-2
IntraSwitch 5324 back panel
24 Fixed 10Base-T Ports
1 Fixed 10/100TX Port
Comprehensive LEDs
Management
Connections
Media Independent Interface (MII)
Power Connector
Power
Switch
Expansion Slots
Redundant Power Supply
Connector
