Installing the sensor – DAVIS External Temperature Sensor with RJ Connector User Manual
Page 2

Installing the Sensor
2
• Place the sensor in a location at least 10 feet away from lights or lamps.
• If you are unsure about a location's exposure to the night sky, check for dew at
that location on a light dewy morning. If the area is dry, the location should
work well.
• Keep the sensor and most of the cable at least 10 feet from 110 Vac, 60Hz utility
power. Do not run the sensor cable parallel to house wiring. Mount the sensor at
least 30 feet from high-voltage power lines and transformers.
Installing the Sensor
The illustration below shows a typical installation for the Envoy in a Davis Multi-
Purpose Shelter (product no. 7728) mounted on a pole.
Weather ENVOY
Typical Installation with Envoy in Multi-Purpose Shelter
