DAVIS Optional AC Charger Kit for Vantage Connect & HD Solar Power Kit (6710) User Manual
Page 3
3
7. Close and lock the shelter.
8. Plug the AC adapter into a power source.
9. To prevent the AC adapter cable from damage caused by whipping in the wind,
it is a good idea to secure it to the pole.
To AC Power Source
Solar Power Cable
Unplugged
Solar Replacement
Adapter Cable
Plugged into
AC Adapter and
Charging Circuit
Vantage Connect with Optional AC Charger Kit Installed
