Alarm Output Module
Mounting the AOM
You may mount the AOM against a wall or other vertical surface or you may
simply set it down on a horizontal surface
Note: Consult the appropriate shelter manual if installing the AOM in either the Complete System
Shelter or the Multi-Purpose Shelter.
✦
To mount the AOM against a wall or other vertical surface, attach the base to the
mounting surface using the #6 x 1” screws.
Use two screws (as pictured below) when attaching to a stud. Use three
screws (as pictured below) in any other case. Tighten the screws until the
base is securely fastened to the mounting surface. Do not overtighten.
A
TTACHING
THE
B
ASE
TO
THE
M
OUNTING
S
URFACE
✦
If you plan to place the AOM on a horizontal surface, attach one of the adhesive
pads to each of the four raised circles on the underside of the base.
A
TTACHING
A
DHESIVE
P
ADS
