3.6.4 System Setup
System Setup allows the programmer to configure the following control panel features:
• Trouble Reminder: This feature, when enabled, provides an audible reminder that an
alarm or trouble still exists on the FACP after the control panel has been silenced.
The control panel piezo sounder will pulse once every 15 seconds during an alarm
and every two minutes during a trouble condition, after the Alarm Silence or
Acknowledge key is pressed. The piezo will continue to sound at these rates until
the alarm or trouble condition is cleared. If the trouble condition is not cleared
within 24 hours, the panel will reactivate the trouble sounder and retransmit the
trouble condition to the central station if connected.
• Banner: This option allows the user to change the top line of the LCD display from
the factory default readout to a user defined readout when the control panel is in
Normal condition.
• Time-Date: This feature allows the programmer to set the time, display format (24
hr or 12 hr), date and daylight savings time feature into the FACP memory
• Timers: This option allows the programmer to set the PAS (Positive Alarm
Sequence) time delay, Pre-Signal time delay and Waterflow time delay.
• NACs: This feature allows the programmer to configure the two control panel
Notification Appliance Circuits for a variety of options, such as circuit type,
silenceable/nonsilenceable, autosilence, coding, silence inhibit, zone assignment
and enable/disable.
• Relays: This option allows programming of two onboard relays for activation by
various control panel events, such as alarm, trouble, supervisory, etc.
Pressing 1 for System Setup, while viewing Programming Screen #2, will cause the
following screens to be displayed:
3.6.4.1 Trouble Reminder
7KH 7URXEOH 5HPLQGHU IHDWXUHV FDXVHV WKH FRQWURO SDQHO SLH]R WR VRXQG D UHPLQGHU
µEHHS¶ IRU DODUPV DQG WURXEOHV DIWHU WKH SDQHO KDV EHHQ VLOHQFHG 5HIHU WR 6\VWHP
6HWXS RQ SDJH IRU D GHWDLOHG GHVFULSWLRQ RI WKLV IHDWXUH 3UHVVLQJ ZKLOH YLHZLQJ
6\VWHP 6HWXS 6FUHHQ ZLOO FDXVH WKH GLVSOD\ WR WRJJOH WR 7URXEOH 5HP 2Q ZKLFK
HQDEOHV WKLV IHDWXUH (DFK SUHVV RI WKH NH\ ZLOO FDXVH WKH GLVSOD\ WR WRJJOH EHWZHHQ
7URXEOH 5HP 2Q DQG 7URXEOH 5HP 2II
PROGRAMMING
1=SYSTEM SETUP
2=AUTOPROGRAM
3=VERIFY LOOPS
Programming Screen #2
@@@@SYSTEM@SETUP
1=TROUBLE@REM@@@@OFF
2=BANNER
3=TIME-DATE
System Setup Screen #1
@@@@SYSTEM@SETUP
1=TIMERS
2=NAC
3=RELAYS
System Setup Screen #2
See Page
