3URJUDPPLQJ 0DVWHU 3URJUDPPLQJ /HYHO
8QLPRGH 31 &
:KLOH YLHZLQJ RQH RI WKH 0RQLWRU 7\SH VFUHHQV VHOHFW WKH W\SH RI PRQLWRU PRGXOH
EHLQJ SURJUDPPHG E\ SUHVVLQJ WKH FRUUHVSRQGLQJ NH\SDG QXPEHU NH\ 7KH GLVSOD\
ZLOO UHWXUQ WR WKH (GLW 0RQLWRU 6FUHHQ ZKLFK ZLOO VKRZ WKH QHZ W\SH VHOHFWLRQ
0RQLWRU PRGXOH W\SH VHOHFWLRQ ZLOO DIIHFW WKH IXQFWLRQ RI WKH SRLQW DV IROORZV
@@@@MONITOR@TYPE
1=DRILL-SWITCH
2=PAS-BYPASS
3=USER-DEFINED-14
Monitor Type Screen #12
Monitor Type Screen #11
@@@@MONITOR@TYPE
1=ACK-SWITCH
2=SIL-SWITCH
3=RESET-SWITCH
Monitor Type Screen #9
@@@@MONITOR@TYPE
1=POWER-MONITOR
2=TROUBLE-MONITOR
3=USER-DEFINED-12
Monitor Type Screen #10
@@@@MONITOR@TYPE
1=PROC-MON
2=PROCMON-AR
3=USER-DEFINED-13
Note: For the PROCMON-AR selection, PROCMON refers to Process Monitor and AR refers to AutoResettable
Monitor Type Action When Activated
Pull-Station Fire Alarm
User-Defined-1 Fire Alarm
Waterflow Fire Alarm Delayed
User-Defined-2 Fire Alarm Delayed
Monitor Fire Alarm
Blank Fire Alarm
User-Defined-3 Fire Alarm
Future Use Future Use
User-Defined-4 Supervisory on partial short, Fire Alarm on full short
Smoke-Conventional Fire Alarm
Heat-Detector Fire Alarm
User-Defined-5 Fire Alarm
User-Defined-6 Fire Alarm
Medic-Alert Supervisory, latching
User-Defined-7 Supervisory, latching
Hazard-Alert Supervisory, latching
User-Defined-8 Supervisory, latching
Tornado-Alert Supervisory, latching
User-Defined-9 Supervisory, latching
User-Defined-10 Supervisory, latching
User-Defined-11 Supervisory, latching
Tamper Supervisory, nonlatching (tracking)
Supervisory Supervisory, latching
Supervisory-AR Supervisory, nonlatching (tracking)
Power-Monitor AC Fault
Trouble-Monitor Trouble
User-Defined-12 Trouble
Proc-Mon Piezo
Procmon-Auto Piezo, nonlatching (tracking)
User-Defined-13 Piezo, nonlatching (tracking)
Ack-Switch Acts like panel Acknowledge Key
Sil-Switch Acts like panel Alarm Silence Key
Reset-Switch Acts like panel Reset Key
Drill-Switch Acts like panel Drill Key
PAS-Bypass PAS Disable
User-Defined-14 PAS Disable
