5HDG 6WDWXV
8QLPRGH 31 &
4.22.12 Print
To print program data or control panel status, press 3 while viewing Read Status Screen
#5. The following screens will be displayed:
Pressing 1 while viewing Print Screen #1 allows the user to print the History file which
will detail all of the system activities since the file was last cleared from memory.
Pressing 2 while viewing Print Screen #1 allows the user to print the Walktest log which
will detail all of the system activations during walktest since the log was last cleared.
Refer to "Walktest" on page 90 for additional information on the display.
Pressing 3 while viewing Print Screen #1 allows the user to print the data of each
addressable smoke detector connected to the system. A printout, similar to the following
example, will be generated if an optional printer is connected to the FACP.
Chamber Value
The Chamber value should be within the indicated range for the following smoke
detectors:
• SD350(T), D350P(R) and SD300(T) Addressable Photoelectric Smoke Detectors:
405 - 2100 (obscuration of 1.00%/ft. to 3.66%/ft.)
• CP350 and CP300 Addressable Ionization Smoke Detectors: 750 - 2100
(obscuration of 0.50%/ft. to 1.44%/ft.)
If the addressable smoke detector’s Chamber reading is not within the acceptable range,
clean the detector and check the Chamber value again. If the reading is still not within the
acceptable range, immediately replace the detector.
1=HISTORY
2=WALKTEST LOG
3=DETECTOR DATA
1=EXIT PRINTING
Print Screen #2
Print Screen #1
DEVICE#
DEVICE TYPE
%DRIFT COMP
CHAMBER
TIME/DATE
1D001
SMOKE (PHOTO)
20
1281
12:01AM 01-08-2001
1D002
SMOKE (PHOTO)
20
1281
12:01AM 01-08-2001
1D003
SMOKE (PHOTO)
21
1259
12:01AM 01-08-2001
1D004
SMOKE (PHOTO)
20
1309
12:02AM 01-08-2001
1D005
SMOKE (PHOTO)
21
1281
12:02AM 01-08-2001
1D006
SMOKE (PHOTO)
20
1322
12:02AM 01-08-2001
1D007
SMOKE (PHOTO)
20
1280
12:02AM 01-08-2001
1D008
SMOKE (PHOTO)
20
1215
12:02AM 01-08-2001
1D009
SMOKE (PHOTO)
20
1310
12:02AM 01-08-2001
