Lokar Automatic Transmission Shifter GM Floor Mount User Manual
Page 4
INS0092 Rev. 06/17/14
Page 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
The bolt can be installed in either
direction, but make sure the
Rod End is sandwiched between
the Flat Washer and the Quad
Arm or Trans Gear Lever.
1/4"-28 x 1"
Button Head Bolt
Quad Arm or
Trans Gear Lever
1/4"-28 Nylock Nut
1/4"-28 Jam Nut
Threaded Rod
Flat
Washer
Rod
End
Selector Shaft
Trans Gear Lever pointing
towards approximately 1:00
3
9
6
12
Measur
e This Distanc
e and Subtr
act 1-3/4"
