User Authentication
3-49
3
Web – Select Security, 802.1x, Statistics. Select the required port and then click
Query. Click Refresh to update the statistics.
Figure 3-29. 802.1x Port Statistics
Rx EAP Resp/Oth The number of valid EAP Response frames (other than Resp/Id frames)
that have been received by this Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received by this
Authenticator in which the Packet Body Length field is invalid.
Rx Last EAPOLVer The protocol version number carried in the most recently received EAPOL
frame.
Rx Last EAPOLSrc The source MAC address carried in the most recently received EAPOL
frame.
Tx EAPOL Total The number of EAPOL frames of any type that have been transmitted by
this Authenticator.
Tx EAP Req/Id The number of EAP Req/Id frames that have been transmitted by this
Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id frames) that have
been transmitted by this Authenticator.
Table 3-5. 802.1x Statistics
Parameter Description
