Access Control List Commands
4-87
4
3. User-defined rules in the Ingress MAC ACL for ingress ports.
4. User-defined rules in the Ingress IP ACL for ingress ports.
5. Explicit default rule (permit any any) in the ingress IP ACL for ingress ports.
6. Explicit default rule (permit any any) in the ingress MAC ACL for ingress ports.
7. If no explicit rule is matched, the implicit default is permit all.
Masks for Access Control Lists
You must specify masks that control the order in which ACL rules are checked. The
switch includes two system default masks that pass/filter packets matching the
permit/deny the rules specified in an ingress ACL. You can also configure up to
seven user-defined masks for an ACL. A mask must be bound exclusively to one of
the basic ACL types (i.e., Ingress IP ACL, Egress IP ACL, Ingress MAC ACL or
Egress MAC ACL), but a mask can be bound to up to four ACLs of the same type.
IP ACLs
Table 4-32. Access Control List Commands
Command Groups Function Page
IP ACLs Configures ACLs based on IP addresses, TCP/UDP port number,
protocol type, and TCP control code
4-87
MAC ACLs Configures ACLs based on hardware addresses, packet format, and
Ethernet type
4-101
ACL Information Displays ACLs and associated rules; shows ACLs assigned to each port 4-111
Table 4-33. IP ACL Commands
Command Function Mode Page
access-list ip Creates an IP ACL and enters configuration mode GC 4-88
permit, deny Filters packets matching a specified source IP address STD-ACL 4-89
permit, deny Filters packets meeting the specified criteria, including
source and destination IP address, TCP/UDP port number,
protocol type, and TCP control code
EXT-ACL 4-90
show ip access-list Displays the rules for configured IP ACLs PE 4-92
access-list ip
mask-precedence
Changes to the mode for configuring access control masks GC 4-92
mask Sets a precedence mask for the ACL rules IP-Mask 4-93
show access-list ip
mask-precedence
Shows the ingress or egress rule masks for IP ACLs PE 4-96
ip access-group Adds a port to an IP ACL IC 4-97
show ip access-group Shows port assignments for IP ACLs PE 4-97
map access-list ip Sets the CoS value and corresponding output queue for
packets matching an ACL rule
IC 4-98
show map access-list ip Shows CoS value mapped to an access list for an interface PE 4-99
