40
Watchdog
The CX-6p-PoE has a watchdog function which can be used to monitor up to four
network-connected devices for failure, and perform user-configurable actions when that
device fails to respond.
When the Watchdog feature is enabled, the CX-6p-PoE will send ping requests
to the target IP address at a frequency determined by the Interval setting. The CX-6p-
PoE will wait for a period of time determined by the Timeout setting for a response to
each ping message. If it does not receive a ping response for a ping, it will increment a
counter which records the number of consecutive failed pings. A single successfully
received ping response will set this counter to zero. When a number of failed ping
responses equal to the Failures setting has occurred, the unit will take some action as
determined by user settings. It will then wait for a number of minutes determined by the
Restart Delay setting before sending any more ping messages.
Setting Default Value Range
Enabled Not Enabled Enabled
Not Enabled
Ping IP Address 0.0.0.0 15 characters
Interval 15 seconds 1-9999 seconds
Timeout 3 seconds 1-9999 seconds
Failures 3 1-9999
Restart Delay 5 minutes 1-9999 minutes
