35
Selecting “Indefinitely” for the duration will simply cause the CX-6p-PoE to set the target
aux contact ON or OFF once and leave it so set.
Buttons are provided which force an ON or OFF message to be sent to the indicated
remote aux output immediately. These are used to test unit configuration and network
connectivity.
IP Message Actions
Address indicates the network IP address and port of the target device. This may be up
to 24 characters long and must consist of an IP address in dotted-quad format, followed
by a colon, followed by a port number in the range of 0 to 32767. The default setting of
“0.0.0.0
:23 ” indicates no action to be taken.
Message – Alarm holds a text message of up to 80 characters. When the local alarm is
triggered this message will be sent to the entered IP address. A ‘test’ button is provided
so that the user may manually test the sending of this message.
Message – Clear holds a text message of up to 80 characters. When the local alarm is
cleared this message will be sent to the entered IP address. A ‘test’ button is provided
so that the user may manually test the sending of this message.
Local Aux Actions
Aux is the number of the aux contact out on the local device to trigger. This number may
be from 1 to 6.
Action selects if the target aux output is to be set ON or OFF in response to the local
alarm condition.
Setting Default Value Range
IP:PORT “0.0.0.0:23” 24 characters
Message – Alarm 80 characters
Message – Clear 80 characters
Setting Default Value Range
Local aux 1-6 1-6
Action state On On
Off
Action duration 5 seconds Follow
1,5,15,30,or 45 seconds
1 or 5 minutes
Indefinitely
