Quick Reference Guide
2
AL: 2005981-ENG Rev. A
Factory Parameters: Serial Port settings
Serial Port Baud Rate Data Bits Parity Stop Bit Interface Levels Update Rate
Serial Port A
4800 19200
9600 38400
8 None 1 RS-232C 1 to 10 Hz
Item Specifi cation
Input voltage 7 - 36 DC
Power consumption <2 W @ 12 VDC (typical)
Current consumption 150 mA @ 12 VDC (typical)
Power connector Cable mount environmentally sealed
Power Specifi cations
Environmental Specifi cations
Item Specifi cation
Operating temperature -30° C to +70° C (-22° F to +158° F)
Storage temperature -40° C to +85° C (-40° F to +185° F)
Humidity 100%
Enclosure Waterproof and dust proof
Compliance FCC, CE
Shock IEC 68-2-27
Vibration ISO 16750-1
EMI Certifi cation FCC part 15, E-mark
LED Status Indicators
Color and Status Indication
Red Power On
Amber GPS Lock
Flashing Green Differential GPS is being acquired
Solid Green Differential GPS is working
