1
Quick Reference Guide
AL: 2002831-50- ENG_B
Direct Command
TM
Serial Communication
Start of Configuration Wizard
Application
4000309-x null
Female
4000315-x standard
Male
To create a configuration, make the following button presses to start the Configuration
Wizard and then follow the instructions given on the display.
To verify the correct harness, the DB9 connector is:
• Female for the 4000309-x (null) cable
• Male for the 4000315-x (standard) cable
DB9
12-pin Deutsch
Application Rate Module with serial cable connecting to Controller
Application Rate Module with serial cable connecting to cable supplied by manufacturer (needed if
listed in following tables) Manufacturer supplied cable connects to Controller.
