Stepper seed control, Quick reference guide, Product control toolbox – Ag Leader Versa DirectCommand Stepper Seed Control Quick Reference Guides User Manual
Page 3
3
Stepper Seed Control
Quick Reference Guide
2006003-ENG Rev A
Actual Rate
actual rate of product being applied as determined
by the stepper motor RPM
Target Rate
desired amount of product to apply
Target Rate #1 & #2
preset planting rates that allow a quick change between rates
Manual Valve Control
allows operator manual control of seed meters
Prescription
allows planting rates to be determined by a loaded prescription
Up and Down Arrows
allow planting rates to be adjusted manually
Settings button
opens Rate Control Settings screen
