Component identification, Front panel, Mechanical components – HP Power Distribution Unit Management Module User Manual
Page 8: Front panel mechanical components
Component identification 8
Component identification
Front panel
NOTE:
This module is used for both the PDR and the UPS. For use in the PDR, see the HP
or the latest firmware.
Item Description
1 ModBus
RTU
2
RJ-11 port (not for PDR use)
3 Power
LED
4 Error
LED
5 Reset
button
6 Network
connector
7
Not for PDR use
8 Config/Pass-Thru
connector
Mechanical components
You must remove the mechanical components installed on the PDR to enable full access to the internal and
operational components inside the rack.
WARNING:
The installation of options, routine maintenance, and service of the PDR must be
performed by individuals who are knowledgeable about the procedures, precautions, and
hazards associated with AC power products. There are no user serviceable components
inside the unit.
