HP PDR Management Module web interface 45
Register Name Panel Breaker Count Format Units
2745 Breaker 212.42 2 1-42 840 UNIT16 0.01 WS
ModBus alarm registers
Use function code 02h to read the discrete input contacts (alarm status).
PDR ModBus alarm registers (1-bit) include:
Register Name Count
1001 Input AC Over Voltage 1
1002 Input AC Under Voltage 1
1003 Input Under Over Frequency 1
1004 Output AC Over Voltage 1
1005 Output AC Under Voltage 1
1006 Output Under Over Frequency 1
1007 Remote Emergency Power Off 1
1008 Building Alarm 4 1
1009 Building Alarm 3 1
1010 Building Alarm 2 1
1011 Building Alarm 1 1
1012 Output Overload 1
1013 Output Current Over 100Percent 1
1014 Eeprom Fault 1
1015 Internal Communication Failure 1
1016 Input Phase Rotation Error 1
1017 Emergency Shutdown Command 1
1018 Level 2 Overload Phase A 1
1019 Level 2 Overload Phase B 1
1020 Level 2 Overload Phase C 1
1021 Level 3 Overload Phase A 1
1022 Level 3 Overload Phase B 1
1023 Level 3 Overload Phase C 1
1024 Level 4 Overload Phase A 1
1025 Level 4 Overload Phase B 1
1026 Level 4 Overload Phase C 1
1027 Transformer Overtemperature 1
1028 Modem Failed 1
1029 Configuration Error 1
1030 Summary Notice 1
1031 Summary Alarm 1
1032 Inverter Phase Rotation 1
