Home tab, Overview menu – HP Power Distribution Unit Management Module User Manual
Page 18
HP PDR Management Module web interface 18
o
The legend displays the meaning of symbols used in the interface. Expand and collapse the
legend by clicking the arrow in the upper right corner.
•
Main frame—Contains the various interface screens based on the menu option selected in the left
navigation frame
Home tab
Menu options listed under the Home tab include:
•
Overview menu (on page 18)
•
Alarms menu (on page 22)
•
Identification menu (on page 25)
•
Overview menu
Click Overview in the left navigation frame to display the Overview screen. This screen displays graphical
information, where colors represent the current state of the PDR.
Color Status
Green Normal
Yellow Warning
Red Critical
NOTE:
The current rating is 400 A for the North American model.
The PDR Output tab graphically displays overall status information for your model.
