HP PDR Management Module Service Menu 49
HP PDR Management Module Service Menu
HP PDR Management Module Service Menu
overview
The HP PDR Management Module Service Menu provides an alternative, limited interface to the
management module when the web interface is disabled or not preferred. The menu structure textually
displays various measurements and warning and alarm messages from the management module. Also,
system values and power fail settings can be configured through the Service Menu and sent to the
management module.
NOTE: All status information and configuration parameters included in the HP PDR
Management Module Service Menu are available using the HP PDR Management Module
web interface (on page 14).
Accessing the Service Menu
You can access the Service Menu:
• Remotely through a telnet session (on page 49)
• Locally through a terminal emulation session (on page 50) using an available serial port
Telnet session
Use a telnet session to access the HP PDR Management Module Service Menu:
1. If necessary, configure the management module:
a. Launch a terminal emulation program ("Launching a terminal emulation program" on page 11).
b. Configure the management module remote access settings ("Configuring the management
module for remote access" on page 12).
2. Be sure that you have connected the network cable ("Connecting the network cable" on page 10) to
the management module.
3. Launch telnet by entering the following command at a DOS prompt or the command line:
Telnet xxx.xxx.xxx.xxx
where xxx.xxx.xxx.xxx is the IP address of the management module.
4. At the prompt, enter the user name and password. The default user name is admin, and the default
password is admin.
For more information about the Service Menu, see "Service Menu (on page 51)."
