Table 9 8Gb SAN Switch physical dimensions
Measurement
Dimension
29.3 mm (1.15 in)
Height
208 mm (8.19 in)
Width
280 mm (11.02 in)
Depth
1.27 kg (2.8 lb)
Weight
Environmental requirements
To ensure proper operation, the switch must not be subjected to environmental conditions beyond
those for which it was tested. The ranges specified in
list the acceptable
environment for both operating and nonoperating conditions.
Table 10 Environmental requirements
Acceptable range during non-operation
Acceptable range during operation
Condition
-40°C to 70°C with maximum rate of change
of 20 C /hr
104°F/40 °C at sea level, derated 1 C per
1000 ft above sea level
Ambient temperature
50% to 80% relative humidity, non-condensing
5% to 90% relative humidity, non-condensing
Humidity
0 to 40,000 ft (12 km) above sea level
0 to 10,000 ft (3 km) above sea level
Altitude
140 G, 2mS,
40 G, 2mS duration
Shock
2.0 G, 5–500 Hz
0.5 G, 10–500 Hz
Vibration
None required
47 cubic ft/minute
Airflow
Supported SFPs
Do not use unsupported SFPs. They may not fit correctly and may void your warranty. Any port
with an unsupported SFP will automatically be disabled by switch firmware, leaving the port
non-operational. See
“Supported SFP transceiver options” (page 9)
for a list of supported SFPs.
For a complete list of supported devices, refer to the latest version of the HP SAN Design Reference
Guide at the HP website:
Supported HBAs
For a list of HBAs that have been tested and are known to work with the SAN switches, see the
latest version of the HP SAN Design Reference Guide at the HP website:
