A SAN Switch technical specifications

Table 8 (page 30)

lists general specifications for the 8Gb SAN Switch for HP BladeSystem c-Class.

General specifications

Table 8 General specifications

Description

Specification

F_Port, FL_Port, and E_Port

Configurable port types

Small Form-Factor Pluggable (SFP) laser. 1/2/4/8Gb short wave up to
500 m (1,640 ft.) and 1/2/4/8Gb long wave up to 10 km

Media types

NOTE:

4Gb SFPs support 1/2/4 Gbps, and the 8Gb SFPs support

2/4/8 Gbps.

An operating SAN Switch conforms to the emissions requirements specified
by the following regulations:

EMC emissions

FCC Rules and Regulations, Part 15 subpart B, Class A

CSA C108.8 Class A

VCCI Class A ITE

CISPR 22 Class A

EN55022 Class A

AS/NZF 3548: 1995 Class A

CNS13438 Class A

ICES-003 Class A

Korean EMC Requirements

BSMI Standard CNS 13438

EMC Directive 89/336/EEC

EN5022 Level A

EN50082-2/EN55024: 1998

EMC immunity

IEC 61000-4-2 Severity Level 3 for Electrostatic Discharge

IEC 61000-4-3 Severity Level 3 for Radiated Fields

IEC 61000-4-4 Severity Level 3 for Fast Transients

IEC 61000-4-5 Severity Level 3 for Surge Voltage

IEC 61000-4-6 Conducted Emissions

IEC 61000-4-11 Voltage Variations

EN 61000-4-12 Oscillatory Waves Immunity

EN 61000-3-2 Limits for Harmonic Current Emissions

EN 61000-3-3 JEIDA

Nonblocking shared-memory switch

System architecture

FC-PH (FC Physical and Signalling Interface standard)

ANSI protocol

FC Class 2, Class 3, and Class F

Modes of operation

2112 bytes

Maximum frame size

Less than 2 microseconds with no contention (destination port is free

Port-to-port latency

Weight and physical dimensions

Table 9 (page 31)

lists physical properties.
