Page 17: Attach usb and power cable to the rdx drive

Figure 5 Connecting to a standard USB port
•
If your server has a special USB port, use the supplied, special USB cable, as illustrated in
on page 17. Select the special cable that is appropriate for the pin layout on the
USB port.
Figure 6 Connecting to a special USB port
Attach USB and power cable to the RDX Removable Disk Backup System
NOTE:
The drive is not powered from the USB bus. It must be connected to the server’s power supply.
1.
Connect the Type B (square) connector on the USB cable to the internal RDX Removable Disk
Backup System.
RDX Removable Disk Backup System
