Chapter 6 Avaya P334T-ML Front and Rear Panels
Avaya P334T-ML User’s Guide 29
SYS System Status
OFF – Module is a slave in a stack
ON – Module is the master of the stack and
the Octaplane and Redundant (optional)
cable(s) are connected correctly.
This LED will also light in Standalone mode.
Blink – Box is the master of the stack and the
Octaplane is in redundant mode.
ROUT Routing Mode
OFF – Layer 2 mode
ON – Router mode
The following Function LEDs apply to all ports
LNK Port Status
ON – Link is OK
OFF – Port is disabled
Blink – Port is enabled, but Link is down
COL Collision
OFF – No collision or full-duplex port for
ports 1 -48; always OFF for ports 51-52.
ON – Collision occurred on line.
Tx Transmit to line
OFF – No transmit activity
ON – Data transmitted on line from the
module
Rx Receive from line
OFF – No receive activity
ON – Data received from the line into the
module
FDX Full Duplex mode
ON – Full duplex mode (ports 1-48)
OFF – Half duplex mode (ports 1-48)
Always ON for ports 51,52 (full-duplex mode
only)
Table 6.1 Avaya P334T-ML LED Descriptions (Continued)
LED Name Description LED Status
