Chapter 3
Avaya P334T-ML User’s Guide 13
Console Pin Assignments
For direct Console communications, connect the Avaya P330 to the Console
Terminal using the supplied RJ-45 crossed cable and RJ-45 to DB-9 adapter.
L Pin 1 of the Modem DB-25 connector is internally connected to Pin 7 GND.
Avaya P330 RJ-45 Pin
Name
(DCE View)
Terminal
DB-9 Pins
Modem
DB-25 Pins
1 For future use NC See note
2 TXD
(P330 input)
3 3
3 RXD
(P330 output)
2 2
4 CD 4 8
5 GND 5 7
6 DTR 1 20
7 RTS 8 4
8 CTS 7 5
