80 HP ProLiant DL560 Server User Guide
Item Description
1 SCSI cable
2 Power button cable
3 Diskette drive cable
4 CD-ROM drive cable
Internal Power Cabling
Item Description
1 SCSI power cable
2 System power cable
3 Power supply signal cable
RILOE II Cabling
The 30-pin Remote Insight cable ships with the RILOE II cable kit. For more
information, refer to the Remote Insight Lights-Out Edition II User Guide on the
Documentation CD.
