Hardware Options Installation 61
• Upgrade memory by installing DIMM pairs into banks in sequential bank
order, starting with bank B.
For online spare memory support, you must also observe additional guidelines
("Online Spare Memory Configuration" on page 60).
Installing DIMMs
1. Power down the server ("Powering Down the Server" on page 29).
2. Extend the server from the rack, if applicable ("Extending the Server from
the Rack" on page 30).
3. Remove the access panel ("Removing the Access Panel" on page 32).
4. Open the DIMM slot latches.
5. Install the DIMM.
6. Install the access panel ("Installing the Access Panel" on page 32).
7. If you are installing DIMMs in an online spare configuration, use RBSU to
configure this feature.
