HP 2312fc and 2324fc Modular Smart Array user guide 63
NOTE: Connections to this device must be made with shielded cables with metallic RFI/EMI connector
hoods in order to maintain compliance with FCC Rules and Regulations.
Physical requirements
The floor space at the installation site must be strong enough to support the combined weight of the rack,
controller enclosures, expansion enclosures, and any additional equipment. The site also requires sufficient
space for installation, operation, and servicing the enclosures, and also requires sufficient ventilation to
allow a free flow of air to all enclosures.
Table 14 and Table 15 list enclosure dimensions and weights. Weights are based on an enclosure having
12 drive modules, two controller or expansion modules, and two power supplies installed.
.
.
Environmental requirements
Table 14 Rackmount enclosure dimensions
Specifications Rackmount
Height 2U 3.5 inches (8.9 cm)
Width:
• Chassis
• To back of power supply handle
21.8 inches (55.4 cm)
23.7 inches (60.2 cm)
Table 15 Rackmount enclosure weights
Specifications Rackmount
2312fc Modular Smart Array
• SAS drives
• SATA drives
64.5 lb (29.3 kg)
65.5 lb (29.8 kg)
2324fc Modular Smart Array
• SAS drives
• SATA drives
58.5 lb (26.6 kg)
54.2 lb (24.6 kg)
MSA2000 3.5 12-drive enclosure (12
drives)
• SAS drives
• SATA drives
62 lb (28.2 kg)
63 lb (28.6 kg)
Table 16
Operating environmental specifications
Specification Range
Altitude To 9842 feet (3000 meters), derate 35.6ºF (2ºC)
for every 3281 feet (1 km) up to 9842 feet (3000
meters)
Relative humidity 10% to 90% RH, 104ºF (40ºC) non condensing
Temperature 41ºF to 104ºF (5ºC to 40ºC)
Shock 5.0 g, 10 ms, half-sine
Vibration 0.5 g, 1 octave/minute, 5 Hz to 500 Hz to 5
Hz, swept-sine
