HP 2312fc and 2324fc Modular Smart Array user guide 45
Are both drive module LEDs off (Online/Activity and Fault/UID)?
Is the drive module Fault/UID LED blinking amber?
Is a connected host port’s Host Link Status LED off?
Answer Possible Reasons Actions
Yes • There is no power.
• The drive is offline.
• The drive is not configured.
• Check that the drive is fully inserted
and latched in place, and that the
enclosure is powered on.
Answer Possible Reasons Actions
No, but the
Online/Activity LED is
blinking.
The drive is rebuilding. No action required.
NOTE: Do not remove a drive that is
rebuilding. Removing a drive might
terminate the current operation and
cause data loss.
Yes, and the
Online/Activity LED is off.
The drive is offline. A predictive
failure alert may have been
received for this device.
• Check the event log for specific
information regarding the fault.
• Isolate the fault.
• Contact an authorized service
provider for assistance.
Yes, and the
Online/Activity LED is
blinking.
The drive is active, but a
predictive failure alert may have
been received for this device.
• Check the event log for specific
information regarding the fault.
• Isolate the fault.
• Contact an authorized service
provider for assistance.
Answer Possible Reasons Actions
No System functioning properly. No action required.
Yes The link is down. • Check cable connections.
• Reseat cables.
• Replace cables.
• In SMU, review the event logs for
indicators of a specific fault in a
host data path component.
