HP 2312fc and 2324fc Modular Smart Array user guide

47

Is the drive enclosure back panel OK LED off?

Is the drive enclosure Fault/Service Required LED amber?

Answer

Possible Reasons

Actions

No

System functioning properly.

No action required.

Yes

The power supply unit or a fan is

operating at an unacceptable

voltage/RPM level, or has failed.

When isolating faults in the power

supply, remember that the fans in both

modules receive power through a

common bus on the midplane, so if a

power supply unit fails, the fans

continue to operate normally.

Check that the power supply FRU is

firmly locked into position.

Check that the AC cord is

connected to a power source.

Check that the AC cord is

connected to the power supply.

Answer

Possible Reasons

Actions

No

System functioning properly.

No action required.

Yes (blinking)

One of the following errors

occurred:

Hardware-controlled

power-up error

Cache flush error

Cache self-refresh error

Check the event log for specific

information regarding the fault.

Isolate the fault.

Contact an authorized service

provider for assistance.

Replace if necessary.

Yes

A fault occurred.
If installing an I/O module FRU,

the module has not gone online

and likely failed its self-test.

Check the event log for specific

information regarding the fault.

Isolate the fault.

Contact an authorized service

provider for assistance.

Replace if necessary.

If installing an I/O module FRU, try

removing and reinstalling the new

I/O module, and check the event

log for errors.
