HP 2312fc and 2324fc Modular Smart Array user guide 23
Figure 2 Cabling connections between a dual-controller enclosure and one MSA2000 3.5 12-drive
enclosure
Figure 3 Cabling connections between a dual-controller enclosure and up to three MSA2000 3.5 12-drive
enclosures
In Out
In Out
1B
1A
2A
2B
In Out
In Out
1B
1A
In Out
In Out
In Out
In Out
2B
2A
3B
3A
4B
4A
