HP 2312fc and 2324fc Modular Smart Array user guide

53

A. Parts catalog

This product contains the parts illustrated

Figure 4

,

Figure 5

, and

Figure 6

.

Parts that are available for customer self repair (CSR) are indicated as follows:

Mandatory CSR

Order the part directly from HP and repair the product yourself. On-site or

return-to-depot repair is not provided under warranty.

Optional CSR

Order the part directly from HP and repair the product yourself, or you can request

that HP repair the product. If you request repair from HP, you may be charged for the repair depending

on the product warranty.

No CSR

The part is not available for customer self repair. For assistance, contact an HP-authorized

service provider.

NOTE:

For an updated list of customer self repair parts, go to

http://www.hp.com/support/

.
