HP Scanjet Enterprise 7500 Flatbed Scanner User Manual
Page 31
4.
Holding the roller assembly door down and out of the way, grasp the roller assembly and slide it
to the left to release it from the enclosure.
CAUTION:
Do not touch the rollers with bare fingers, as oils from your fingers could impact
performance.
NOTE:
You might feel a slight resistance when sliding the roller assembly.
CAUTION:
Take care not to press down on the alignment tabs or against the tab to the right of
the roller assembly.
5.
Lift the roller assembly out and set it aside.
ENWW
Replace the rollers
25
