5-4
Understanding Adaptec Storage Manager
Collapsed and Expanded Views
You can display a collapsed or expanded view of the system
configuration. Initially, Storage Manager displays a collapsed
textual view of the configuration information in both the Logical
devices and Physical devices views.
In the Logical devices view...
Click to expand and collapse information about disk groups and
logical devices. The expanded display shows the following
information about each logical device:
■ Disk group name and capacity (if available)
■ Logical device size
■ Logical device state
■ Build progress
In the Physical devices view...
Click to expand and collapse information about physical drives.
The expanded display shows the following information about
each drive:
■ Capacity of the drive
■ Drive ID
■ Drive state
