ENGLISH
USER MANUAL
14
33019476(3)2010-02 A
RS 2200
R754 EU4 diesel engine data
(*)
Values
Make
VM MOTORI
Type
R754EU4
Cylinders
4
Displacement
181.2 in
3
(2,970 cm
3
)
Maximum calibrated engine speed
2,300 rpm
Maximum engine speed without load
2,550 rpm
Maximum working speed
1,850 rpm
Maximum power
95.2 CV (70 kW)
Maximum torque
251 lb·ft (340 N·m) @ 1,350 rpm
Emissions
2005/78/EC EURO4 - 2004/26/EC STEP3A
Idle speed
800 rpm
Engine coolant
50% of AGIP antifreeze and 50% of water
Antifreeze type
Agip Antifreeze Extra (**)
Engine oil type
Agip Sigma Super TFE 10W40 (***)
Engine oil pan capacity
13.9 lb (6.3 kg)
Consumption in running conditions during transport
2.8 USgal/h (10 l/h)
Consumption in running conditions during operation
2.6 USgal/h (9.5 l/h)
For other diesel engine data/values, see the relevant Manual.
(*)
See the engine oil technical data and reference data tables below.
(**)
See the coolant technical data and reference data tables below.
(***)
AGIP ANTIFREEZE EXTRA SPECIFICATIONS
Approvals and specifi cations
Boiling point
°C/°F
170/338
CUNA NC 956-16 97
Boiling point in solution with 50% water
°C/°F
110/230
FF.SS cat. 002/132
Freezing point in solution with 50% water
°C/°F
-38/-36.4
ASTM D 1384
Colour
/
Turquoise blue
Density at 15 °C
kg/l
1.13
AGIP SIGMA SUPER TFE 10W40 SPECIFICATIONS
Approvals and specifi cations
SAE QUALITY
/
10W40
ACEA E4, E5,E7, B4
Viscosity at 100 °C/212 °F
mm
2
/s
14.5
API CH-4, CF/SL
Viscosity at 40 °C/104 °F
mm
2
/s
107
MAN M 3277 + M3277 low ash
Viscosity at -25 °C/-13 °F
mPa/s
6,400
VW 505.00 level
Viscosity index
/
138
RVI RXD
Flash point COC
°C/°F
220/428
CAT-TO 2
Pour point
°C/°F
-27/-16.6
ALLISON C-4
Density at 15 °C
kg/l
0.876
Mercedes Benz 228.5 + 229.1
VOLVO VDS2
MTU typ 3
ZF TE ML 04C
DEUTZ DQC IV 05 level
ISOTTA FRASCHINI
Refuelling data
Values
Fuel tank capacity
22.2 USgal (84 litres)
Hydraulic system oil tank capacity
21.1 USgal (80 litres)
