ENGLISH USER MANUAL
12 33019476(3)2010-02 A RS 2200
Machine layout description (Continues)
(See Fig. G)
Cab 1.
High-pressure washing system 2.
Hydraulic system oil level indicator 3.
Hydraulic system oil tank 4.
Left front water tank 5.
Left rear water tank 6.
Left rear drive wheel 7.
Left front wheel 8.
Left side water tank drain plug 9.
Left front water tank fi ller plug 10.
Right front water tank fi ller plug 11.
Left rear water tank fi ller plug 12.
Right rear water tank fi ller plug 13.
Hydraulic system oil tank fi ller plug 14.
Combined radiator 15.
Windscreen wiper fl uid tank 16.
Fuel fl oat 17.
Hydraulic system combined fi lter 18.
Hydraulic system return fi lter 19.
Diesel engine 20.
Rear fl ashing light 21.
Expansion tank 22.
Rear light 23.
Back-up light 24.
Retrorefl ector 25.
Front fl ashing light 26.
Windscreen wiper motor 27.
Towing hook 28.
Right rearview mirror 29.
Left rearview mirror 30.
FX.6 fuse 31.
Electrical component box 32.
FX.5 fuse 33.
FX.4 fuse 34.
FX.3 fuse 35.
Upper turn signal 36.
Battery release switch 37.
Left front water tank lower fastener 38.
Left front water tank upper fastener 39.
Filler hose 40.
FX.2 fuse 41.
FX.1 fuse 42.
3rd broom 43.
Rear bumper 44.
Right broom 45.
Left broom 46.
Dust control system tank fi lling fi lter 47.
Front working light 48.
Rear working light 49.
Rear suction pipe 50.
Upper headlights 51.
Diesel particulate fi lter (DPF) 52.
Hopper inspection door 53.
Hopper water recirculation fi ller neck 54.
High-pressure washing system intake 55.
Licence plate light 56.
Right upper inspection door 57.
Left upper inspection door 58.
Camera kit description (optional)
(See Fig. AO)
Display 1.
ON/OFF switch 2.
Display locking lever 3.
Front camera 4.
Rear camera 5.
