USER MANUAL ENGLISH
RS 2200 33019476(3)2010-02 A 13
TECHNICAL DATA
Dimensions and weights Values
Machine length 208.7 in (5,300 mm)
Machine width (without rearview mirrors) 47.2 in (1,200 mm)
Distance between front and rear wheels 90.2 in (2,290 mm)
Front/rear wheel base 36.6 in (930 mm)
Machine height (without fl ashing light) 78 in (1,980 mm)
Machine height with fl ashing light 86.6 in (2,200 mm)
Minimum distance from the ground (skirts not included) 7.5 in (190 mm)
Maximum front working angle 15°
Maximum dumping height 63 in (1,600 mm)
Front/rear tyres 215 - 75 - R16
Tyre pressure 87 psi (6 Bar)
Left/right broom diameter 29.1 in (740 mm)
3rd broom diameter 31.5 in (800 mm)
Total machine weight, in running condition (without operator) 7,562 lb (3,430 kg)
Total mass 9,921 lb (4,500 kg)
Machine tare weight (with/without 3rd broom) 6,944/6,924 lb (3,150/3,050 kg)
Performance data Values
Maximum forward speed (for transport only) 13.7 mph (40 km/h) (*)
Maximum working speed 7.4 mph (20 km/h)
Maximum reverse speed 5.0 mph (8 km/h)
Gradeability at full load 22%
Wall-to-wall turning radius 145.3 in (3,690 mm)
Front leaf spring lifting 70 mm
Maximum side broom speed 0-200 rpm
Collection system Suction
Cleaning width with 2/3 brooms 74.8/98.4 in (1,900/2,500 mm)
Productivity (hypothetical/actual) 46,500,093/32,550,065 in 2 /h (30,000/21,000 m 2 /h)
Filtering system Metallic net
Vibration level at the operator’s arms/body 17.2/15.5 in/s 2 (0.436/0.394 m/s 2 )
Sound pressure level at workstation (ISO/EN3744) at maximum working speed 80 dB(A)
Certifi ed sound power (2000/14/EC) at maximum working speed 110 dB(A)
Measured sound power (ISO/EN3744) at maximum working speed 107 dB(A)
Hopper capacity 581.2 USgal (2,200 litres)
Hopper maximum load (with/without 3rd broom) 2,976/3,197 lb (1,350/1,450 kg)
Dust control system By water
Total dust control system water tank capacity 84.5 USgal (84 litres)
Tail lights Road type
Transmission Hydrostatic servoassisted
Steering system Tractor and semitrailer with power steering
Brake Hydraulic, on all wheels
Parking brake Mechanic, on front wheels
Controls Electrohydraulic
Autonomy (work/transport) 8.8/8.4 hours
For machines without speed change system, the maximum speed is 25 km/h. (*)
