Setting Item
Details
Air Drying
If the Dry Separated Chart check box is clear, printing and air drying the color chart
are performed once. This reduces the time taken by the operation, but may scratch
or soil the end of the color chart and paper. However, this does not affect the color
measurement results.
Position of Ventilation Fan
If you are using paper that has a tendency to curl or paper that does not dry easily,
select High so that the paper does not come into contact with the paper presser.
Note that when High is selected, we recommend that you set the Time longer and
the Airflow stronger compared with when Standard is selected because of the larg-
er distance between the ventilation fan and paper.
8
The View Settings window is displayed. Check the de-
tails of the settings and click the OK button.
Note
•
Click the Add to Favorites button to display the Add to Favorites dialog box, which allows you to add the setting
details to favorites.
9
The Output Color Measurement Data dialog box is
displayed.
Select the file to save the color measurement data into
and click the OK button.
