8. Main Specifications and Performance
-67-
8.2 Functions in the Observation and Photography Modes
The following table shows the availability of functions when each of the observation modes is used with
each photography mode. Available options are indicated with the check mark “9”. Unavailable options are
indicated with “N/A.” The table also shows specifications in the respective observation and photography
modes.
*1 COL: COLOR mode
*2 RF:
RED FREE mode
*3 COB: COBALT mode
Function
Non-Mydriatic Mode Mydriatic Mode
COL *1 RF *2 COB *3 FLUO FAF COL *1 RF *2 COB *3 FLUO FAF
Viewfinder N/A 9
Observation
Monitor
9 N/A
Observation
Illumination
Near-infrared Visible light
Field Angle 45° 50°
Used Eye
Fixation Lamp
Internal or external eye fixation lamp External eye fixation lamp
Focus Indicator 9 9
Working Distance
Dot
9 9
Minimally
Required Pupil
Diameter
4.3 mm 5.1 mm
x2 Photography 9 9
Small Pupil
Photography
Function
9 with pupil size of
ø 3.8 mm
N/A
9 with pupil size of
ø 4.3 mm
N/A
Timer N/A 9 N/A N/A 9 N/A
Barrier Filter N/A N/A 9 N/A
